SIGTRONICS’ EGT 101
…The Digital EGT with a Difference!
Now you can upgrade
to DIGITAL without
replacing your probe.
Just pull out the old
analog and slip in the
New EGT 101; connect
to power and enjoy
Digital Accuracy,
Convenience and
Reliability!!
■ UNIQUE built-in isolation power supply allows you to
use the EGT 101 to replace any EGT which uses the
conventional alumel/chromel (K Type) probe, regardless
of the probe “grounding” configuration. The K Type
probe, identified by it’s red (-) and yellow (+) lead
terminations, has been the standard probe for many
years.
■ LARGE LCD DISPLAY is easy to view in the sunlight.
Back lighting is provided for night flying. The lighting
circuit can also be connected to the aircraft panel light
dimmer circuit.
■ 1
°
F RESOLUTION allows precise fuel leaning for
maximum economy and engine protection. Typical analog
gauges offer only 25
°
of resolution. Parallax error, resulting
from variance in viewing angle, further degrades the
readability of the analog gauge.
■ ADVANCED DESIGN totally eliminates the need for
costly field calibration during installation. The EGT 101 is
designed to read thermocouple voltage directly, therefore
the accuracy is not affected by thermocouple wire length
or gauge.
SPECIFICATIONS:
Single channel, however a switch may be installed for
multi-channel applications.
Probe input: Single alumel/chromel (K Type) probe.
Polarity marked mounting studs on rear of case.
Accuracy: ± 0.5% at 1500 ° F
Weight: 4.2 ounces
Dimensions: 2.5” x 2.5” x 3.5” deep
Voltage Requirement: 10-34VDC
Operates on 12V or 24V systems
Current Drain: 0.015 amps,
exclusive of lighting system.
Warranty: One year parts and labor
Form EGT-2 Made in U.S.A.
