Sigtronics 900116 User Manual
Page 3
Kenwood
TK- 620 / 622 / 630 / 705 / 710 / 715 / 720 / 722 / 730 / 760 / 760H / 762 /
762H / 805 / 810 / 815 / 820 / 822 / 830 / 840 / 860 / 860H / 862 / 862H
/ 930 / 931 / 940 / 941
Function
6 Pin
Sigtronics Wire Color
MIC HI
B
Brown
MIC LO
C
Black
PTT HI
D
White
PTT LO
E
White
Sigtronics Universal Mobile Radio Microphone Interface “Y” Adapter 6 Pin
Motorola
• Centro
• Compact
• MC Micro
• Mostar
• M110 Radius
• T340 Radius
Function
6 Pin
Sigtronics Wire Color
PTT HI
C
White
MIC HI
D
Brown
MIC LO
E
Black
PTT LO
F
White
Relm - Regency
• LMV2548B
• RML60
• RMV60
• SLU25
• SLV40
• SMU Series
• SMV Series
Function
6 Pin
Sigtronics Wire Color
MIC LO
B
Black
PTT LO
B
White
PTT HI
C
White
MIC HI
D
Brown
Ritron
• RPM-050 Patriot
• RPM-150 Patriot
• RPM-160 Patriot
• RPM-450 Patriot
• RPM-460 Patriot
Function
6 Pin
Sigtronics Wire Color
MIC LO
A
Black
PTT LO
A
White
MIC HI
B
Brown
PTT HI
C
White
Maxon
• SM-2150
• SM-2450
• SM-4150
• SM-4450
Function
6 Pin
Sigtronics Wire Color
MIC LO
A
Black
PTT LO
A
White
MIC HI
D
Brown
PTT HI
E
White
Tait
• T700 Series
• T2000 Series
Function
6 Pin
Sigtronics Wire Color
PTT HI
C
White
MIC HI
D
Brown
PTT LO
E
White
MIC LO
E
Black
Raytheon
ACU-2000IP
Function
6 Pin
Sigtronics Wire Color
PTT LO
A
White
MIC LO
B
Black
MIC HI
E
Brown
PTT HI
F
White
Raytheon / JPS Communications
ACU-1000
Function
6 Pin
Sigtronics Wire Color
PTT LO
A
White
MIC LO
B
Black
MIC HI
E
Brown
PTT HI
F
White
Yaesu
• FT-1500M
• FT-1802M
• FT-1900R
• FT-2800M
• FT-2900R
• FT-7100M
• FT-7800R
• FT-7900R
• FT-8800R
• FT-8900R
Function
6 Pin
Sigtronics Wire Color
MIC LO
D
Black
PTT LO
D
White
MIC HI
E
Brown
PTT HI
F
White
