13
PARTS LIST:
SGO1E / SGO1E-2 SGO2E / SGO2E-2
(EX1 / EX1-2 EX2 / EX2-2)
Description 115V 220V
Cord Set 1800510 1800500
Door Gasket 3450722 3450722
Door Handle 3800610 3800610
Filter EMI 2800502 2800502
Fuse 3300516 3300515
Fuse Holder N/A 3300501
Inlet with Fuse Drawer 4200505 N/A
Heating Element, SGO1E / SGO1E-2 (EX1/ EX1-2) 9570637 9570642
Heating Element, SGO2E / SGO2E-2 (EX2/ EX2-2) 9570640 9570644
Knob, Main Temperature 4450528 4450528
Knob, Over Temperature 4450506 4450506
Main Temperature Controller 1750863 1750863
On/Off (I/O) Switch 7850570 7850570
Over Temperature Thermostat 1750615 1750648
Pilot Light, green 4650554 4650554
Pilot Light, red 4650553 4650553
Shelf Clips 1250511 1250511
Shelf, SGO1E / SGO1E-2 (EX1/ EX1-2) 5080538 5080538
Shelf, SGO12 / SGO2E-2 (EX2 / EX2-2)
5080539 5080539
Thermometer 8200509 8200509
Thermometer Clip 5080865 5080865
UNIT SPECIFICATIONS
Weight Shipping Net
SGO1E / SGO1E-2 (EX1/ EX1-2) 45 lbs. 38 lbs.
SGO2E / SGO2E-2 (EX2/ EX2-2) 67 lbs. 60 lbs.
Dimensions Exterior WxDxH Interior
WxDxH
SGO1E / SGO1E-2 (EX1/ EX1-2) 18X16.5X21.25” 12 X 12 X 14 ”
SGO2E / SGO2E-2 (EX2/ EX2-2) 21 X 17.5 X 23.5” 17 X 12 X 17”
Capacity Cubic Feet
SGO1E / SGO1E-2 (EX1/ EX1-2) 1
SGO2E / SGO2E-2 (EX2/ EX2-2) 2
Temperature Range Uniformity
SGO1E / SGO1E-2 (EX1/ EX1-2) Amb+5° to 200

C +4

C
SGO2E / SGO2E-2 (EX2/ EX2-2) Amb+5° to 200

C +4

C
SECTION
9
