15
PARTS LIST SMO5E / SMO5E-2
(1327F / 1375F-2)
Description 115V 220V
Main Temperature Control 1750863 1750863
Over Temperature Control 1750615 1750648
Cord Set 1800516 1800537
Door Handle 3800610 3800610
Heating Element 1327F 9570778 N/A
On/Off Switch 7850570 7850570
Knob Main Temperature 4450528 4450528
Knob Over Temperature 4450506 4450506
Pilot Light Green 4650554 4650554
Pilot Light Red 4650553 4650553
Shelf Clips 1250511 1250511
Shelf 5130714 5130714
Thermometer Clip 5080865 5080865
Thermometer 8200509 8200509
Filter EMI 2800502 2800502
Fuse 3300516 3300515
Inlet with Fuse Drawer 4200505 4200505
Fuse Holder N/A 3300501
UNIT SPECIFICATIONS
Weight Shipping Net
SMO5E SMO5E-2
(1327F 1327F-2)
153 lbs. 113 lbs.
Dimensions Exterior WxDxH Interior WxDxH
SMO5E SMO5E-2
(1327F 1327F-2)
24 X 24.5 X 37” 20 X 17.5 X 28”
Capacity Cubic Feet
SMO5E SMO5E-2
(1327F 1327F-2)
5.7
Temperature Range Uniformity
SMO5E SMO5E-2
(1327F 1327F-2)
Amb+5° to 200

C +4

C
