Shellab SMI39-2 - Manual (Page 17)

17
WIRE DIAGRAM
SMI31 (RI28) 120V
(9851242)
MAIN POWER SWITCH CHERRY ROUND
7850532
POWER LIGHT ~ 4650554 (G)
OTP LIGHT 4650553
(R)
HEAT LIGHT 4650554(G)
CHAMBER FAN ~ 4880548
½ TB1
L1
½ TB1
L2
1 2
4
OTP
1750862
CONVENIENCE
OUTLETS
6100525 x4
DESIGN = 750W / 120V / 19.2 
BLK BLK
BLK WHT
WHT
BLK
BLK HT WHT HT
BLK
BLK WHT
WHT BLK BLK BLK
BLK
BLK BLK BLK
WHT WHT WHT
WHT
BLK WHT
CHART RECORDER
CONNECTIONS
RED
BLU WHT
BLK
WHT BLK
BLK WHT
BLK BLK
0900503
0.47  F / 250 VAC
HOT
NEUTRAL
GROUND
LOAD
TEMPERATURE
CONTROL
1750982
2800503
IEC FUSED INLET
4200505
BLK
WHT
BLK WHT
