How to Fold the Tower (If Needed): First, fully loosen
and remove all 6 Short Screws (marked “B” in the picture
above) from the unit. Next, fully loosen (about 5 turns),
but do NOT remove, the 6 remaining pre-inserted Long
Screws (marked “A” in the picture above). Finally,
carefully fold down the unit. Please note that the unit
CANNOT be folded completely flat. Forcing the unit into a
folded position without first removing the 6 Short Screws
(B) and fully loosening the 6 pre-inserted Long Screws (A)
may result in irreparable damage to the unit.
Step 2: Refer to the picture below. First, tighten the 6
pre-inserted Long Screws (marked “A” in the picture).
Next, screw in and tighten the 6 Short Screws (B) into the
6 screw holes on the unit (these screw holes are marked
“B” in the picture). Do NOT over tighten the screws.
Assembly Instructions (Page 3 of 5)
Step 1: Use a Phillips screwdriver to loosen the 6 Long
Screws (A) that have already been pre-inserted in the unit.
Do NOT remove the screws from the unit. Simply loosen
them to allow the unit to unfold. Next, place the
compressed unit horizontally and position your hands to
carefully unfold the unit.
2) Find a flat surface or floor to assemble the unit. Using
an uneven surface or floor to assemble the unit may result
in uneven/unlevel shelves.
3) If the unit is uneven/unlevel after assembled, loosen
both screws (A & B), adjust the unit and then retighten the
screw (A & B).
1) Do NOT place the unit vertical when unfold as this may
result in the unit suddenly unfolding and pinching your
fingers.
Assembly Instructions (Page 2 of 5)
Please Note:
(A) (B)
Folded 3-Tier Tower (1 pc)
(A) Long Screw (6 pcs)
pre-inserted in the unit
(B) Short Screw (6 pcs)
Please check the parts you received according to the
parts list below. If you are missing any parts, please
contact our Customer Service Department. (Please refer
to page 4 of 5)
*Tool needed: Phillips Screwdriver
Parts List (Page 1 of 5)
