6
V
ECTOR
™ P
YROELECTRIC
D
ETECTOR
S
PECIFICATIONS
:
Model P 25 PHF 25 PHD 25 PHDX 25 PHDX25UV SP 25 SPHF 25 SPHD 25
Aperture Diameter 25.4 mm 25.4 mm 25.4 mm 7mm 7mm 25.4 mm 25.4 mm 25.4 mm
Spectral Response .193-10.6µm .4-2µm .193-2µm .193-10.6µm
Maximum Average Power
Minimum Energy
Noise Equivalent Energy
4 µJ
Maximum Energy Density Note 2 Note 3 Note 4 Note 2
Accuracy 5% 5% 8%^ 8%^ 8%^ 5% 5% 8%^
Output Sensitivity 8 V/J 8 V/J 2 V/J 2 V/J 2 V/J 8 V/J 8 V/J 2 V/J
Maximum Repetition Rate 100 pps 400 pps 40 pps 40 pps 40 pps 100 pps 400 pps 40 pps
Maximum Pulse Duration 0.2 msec 0.045 msec 0.2 msec 0.2 msec 0.2 msec 0.2 msec 0.045 msec 0.2 msec
Dimensions D x L - inches 2.4 x 2.3 2.4 x 2.3 2.4 x 2.3 2.4 x 3.9 2.4 x 3.9 2.3x2.3x0.6 2.3x2.3x0.6 2.3x2.3x0.6
cm 6.1 x 5.8 6.1 x 5.8 6.1 x 5.8 6.1 x 9.9 6.1 x 9.9 5.8x5.8x1.4 5.8x5.8x1.4 5.8x5.8x1.4
Weight - pounds/kgs 0.9/1.4 0.9/1.4 0.9/1.4 1.1/0.5 1.1/0.5 0.3/0.14 0.3/0.14 0.3/0.14
Indicator Compatibility H410, H410D, S310, S310D, D200PC, D200P
Model P 50 PHF 50 PHD 50 PHDX 50 PHDX50UV SP 50 SPHF 50 SPHD 50
Maximum Beam Diameter 50.8 mm 50.8 mm 50.8 mm 15 mm 15 mm 50.8 mm 50.8 mm 50.8 mm
Spectral Response .193-10.6µm .4-2µm .193-2µm .193-10.6µm
Maximum Average Power
Minimum Energy
Noise Equivalent Energy
Maximum Energy Density
Note 2 Note 3 Note 4 Note 2
Accuracy 5% 5% 8%^ 8%^ 8%^ 5% 5% 8%^
Output Sensitivity
Maximum Repetition Rate
50 pps 400 pps 20 pps 20 pps 20 pps 50 pps 400 pps 20 pps
Maximum Pulse Duration 0.4 msec 0.045 msec 0.4 msec 0.4 msec 0.4 msec 0.4 msec 0.045 msec 0.4 msec
Dimensions D x L - inches 3.5 x 2.3 3.5 x 2.3 3.5 x 2.3 3.5 x 3.9 3.5 x 3.9 3x3x0.6 3x3x0.6 3x3x0.6
cm 8.8 x 5.8 8.8 x 5.8 8.8 x 5.8 8.8 x 9.9 8.8 x 9.9 7.6x7.6x1.5 7.6x7.6x1.5 7.6x7.6x1.5
Weight - pounds/kgs 1.5/0.68 1.5/0.68 1.5/0.68 1.7/0.77 1.7/0.77 0.4/0.18 0.4/0.18 0.4/0.18
Indicator Compatibility H410, H410D, S310, S310D, D200PC, D200P
^Beam centered on absorber
Note 1:
Max J/cm2 =316 x (pulse width)1/2
Note 2: HD models Max J/cm 2 = 4500 x (pulse width) 1/2 to a maximum of 1.4 J/cm 2 .
Maximum pulse width of the pyroelectric detector must be observed.
Note 3: HDX models Max J/cm 2 = 36,000 x (pulse width) 1/2 to a maximum of 12.6 J/cm 2 .
Maximum pulse width of the pyroelectric detector must be observed.
Note 4: HDXUV models Max J/cm 2 = 18,000 x (pulse width) 1/2 to a maximum of 5.6 J/cm 2 .
Maximum pulse width of the pyroelectric detector must be observed.
2 V/J
Note 1 Note 1
Note 1 Note 1
16 µJ
7% of selected range
5 W with full illumination of the detector
10 W with full illumination of the detector
.193-26µm .193-26µm
.193-26µm .193-26µm
7% of selected range
