9560,9561,9562 KL, KR, KT _ _
To w e l B a r
Measure the dimensions carefully, mark the four screw hole positions
by using the Mounting Hardware Post.
Using a drill, pre-drill the holes.
Insert Anchors into the wall.
Secure the Mounting Hardware Posts by tightening the Screws into the
Anchors.
Installing On Solid/Hard Surface
Measuring the Mounting Hardware Posts
At the wall, measure the 18”, 24”, or 30” distance from the center of
the secured Mounting Hardware Post to where the other will go and
mark the measurement with a pencil. Place the center of the other
Mounting Hardware Post over the mark and check with a level to make
sure the height of both is the same. When level and centered, mark the
screw hole positions.
Follow the previous installation instructions to secure the second
Mounting Hardware Post.
