INSTALLATION INSTRUCTIONS
S POUT I NSTALLATION
FLUSH BOTH SUPPLY LINES BEFORE INSTALLATION.
AFTER FLUSHING, SHUT OFF BOTH SUPPLY LINES.
MINIMUM HOLE SIZE FOR THE SPOUT AND HANDLE TRIM IS 1-1/4”
AND MAXIMUM IS 1-1/2”
1. Remove the tee connector and spout mounting hardware from
quick connect shank being sure to leave on brass plate.
2. Apply a ring of silicone caulking around hole designated for spout.
DO NOT USE PLUMBERS’ PUTTY, WHICH CAN DAMAGE FINISH.
3. From the top of the deck, slip the quick connect shank through
the assig ned spout hole.
4. Secure the quick connect shank by putting the washer and lock nut
back on the shank. Tighten the lock nut firmly.
5. From the top of the deck, slip the spout with the flange and flange
washer onto the quick connect shank top. Align the spout and tighten
the set screw with the Allen key provided.
6. Connect the tee connector to the spout shank.
S ILIC
ONE
ROMAN TUB WITH HAND HELD
COLLECTION
