SPOUT ASSEMBLY IS READY FOR SIMPLE DROP-IN INSTALLATION. DO NOT DISASSEMBLE.
Spout
Spout Installation Spout Installation
Remove the washer and lock nut from the valve body.
Apply a ring of silicone caulking around the spout hole
on the sink or counter top (do not use plumber’s putty
which can damage the finish of your faucet).
Insert lavatory assembly through the spout hole. Make
sure to center the lavatory over hole.
A
Re-install the washer and lock nut from below.
Hand tighten lock nut from below while properly aligning
the fixture.
Secure from below with an adjustable wrench and
connect the inlet hoses to the supply lines. Make sure
that the hot inlet hose connects to the hot supply line,
and the cold inlet hose connects to the cold supply line.
B
Carefully fit the lift rod into the back of the fixture.
C
IMPORTANT: After all the connections have been made from inlet supplies to angle stop, remove
the aerator. Open the lever on the lavatory. Slowly open angle stop from below and flush the lines
for approximately 45 seconds to clean any debris. Turn off the water and reinsert aerator. Debris
present in the line will damage fixture and cause leaking. Failure to flush fixture could result in possibly
voiding warranty.
D
Spout
Washer
Lock nut
Lift rod
