E S T A T E S E R I E S B R A V O C O L L E C T I O N
S I N G L E C O N T R O L L A V A T O R Y
M O D E L : 6 6 8 0 B O 1 0
6 6 8 0 B O 7 5
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
I m p o r t a n t : P l e a s e re g i s t e r y o u r p ro d u c t o n l i n e a t w w w. s a n t e c f a u c e t . c o m w i t h i n
3 0 d a y s o f p u rc h a s e . S a n t e c re s e r v e s t h e r i g h t t o re q u e s t a d d i t i o n a l d o c u m e n t s
b e f o re s e r v i c i n g w a r r a n t y re q u e s t s .
0 1 0 2
Spout
Hole size for the spout is a minimum of 1-3/8” and a maximum of 1-7/16”.
Washer
Lock nut
3
8 "
3
4 "
1
2 "
1 4 "
15 16 "
7
16 "
