Santec 3524TX - Manual

MODENA BRIDGE COLLECTION MODENA BRIDGE COLLECTION
4” SPREAD BRIDGE LAVATORY SET WITH “TX” STYLE HANDLES 4” SPREAD BRIDGE LAVATORY SET WITH “TX” STYLE HANDLES
## PART PART DESCRIPTION DESCRIPTION PART # PART #
11
22
33
44
Complete Centerset Faucet Bridge Assembly
with ‘TX’ handles 4 inch* Complete Centerset Faucet Bridge Assembly
with ‘TX’ handles 4 inch*
Mounting Pack Mounting Pack
Rubber Washer Flange Rubber Washer Flange
Lift and Turn Pop drain assembly Lift and Turn Pop drain assembly
PS-2D00XA PS-2D00XA
PM-898 PM-898
KB-252 KB-252
* Please specify the finish when ordering the part. * Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
4 4
PAGE 01
3524TX _ _-_ _
ITEM NUMBER
2
3
2
PM-400 PM-400
3
11.406”
7.384”
4”
6.442”
1
5.25”
7.5”
6.157”
3.5”
Ш 2.175”
