H ANDLE T RIM I NSTALLATION
Step 1
· Unscrew pre-assembled handle trim
from the valve body. Hot valve
assembly “Red” to be mounted on
left. Cold valve assembly “Blue” to
be mounted on right.
Step 3
· Slip valve body up from below tub
deck.
· Reattach pre-assembled handle trim
to the valve body.
Step 2
· Apply a ring of silicone caulking
around the handle hole on deck top.
DO NOT USE PLUMBERS’ PUTTY,
WHICH CAN DAMAGE FINISH.
Step 4
· Align handles with respect to the
spout and tighten bottom lock nut
until secure.
Tub deck
Fiber gasket
Lock nut
INSTALLATION INSTRUCTIONS
PAGE 03
ROMAN TUB WITH HAND HELD
COLLECTION
SILI CON
E
