Clarion DGL373 - Manual (Page 20)

20
DGL373
8. SPECIFICATION
Compliance Bluetooth ® 1.2
Profiles A2DP (stereo music streaming)
AVRCP (remote control function, e.g. play/pause,
next/previous track)
Wireless range Class 2: Up to 10m (line of sight)
Tx/Rx radio sensitivity -80dBm
Data rate
Forward: 723kbps Reverse: 57kbps
Antenna 2.45 GHz chip type
Compression SBC (sub-band coding)
Compression ratio 4:1-6:1 typical
Bit rate Programmable (<350kbps typical)
Stereo audio 16kHz-48kHz, 16bit (for music)
iPod support MMI support for iPod e.g. play/pause, next/
previous track etc
Audio bandwidth 30Hz-20kHz
Signal-to-Noise Ratio ~84dB
Analog in Line level (1 Vrms)
Voltage 3.7V
Max current 60mA
Battery life (full running) ~8hr on 3.7v 500mAh polymer lithium ion battery
Charging time
~2hr on 3.7v 500mAh polymer lithium ion battery
Power source 4.5-6.5V DC
Operating temperature
-40°C~85°C Storage temperature
-20°C~60°C
Dimensions Approx. 35mm (Width) x 74mm (Height) x 10mm
(Depth)
Weight Approx. 26g
