-4-
GROUNDING
This appliance must be grounded to protect the
operator from electric shock during use. For this
purpose, it is equipped with a three-conductor power
cord and three-prong grounding-type plug (Figure
A). The plug only fits three-hole electric receptacles.
For the plug to fit a two-hole receptacle, you will
need a Grounding Plug Adapter with a wire or metal
tab (Figure B). Connect the wire/tab to the electrical
outlet with the cover plate screw. The screw must
be metal. The electrical box must be properly
grounded (Figure C).
EXTENSION CORDS
When using an extension cord with this appliance,
only use a three-wire extension cord with a
three-prong grounding-type plug and three-pole
connector. The extension cord must have an
electrical rating equal to or greater than that of the
appliance. Do not use a damaged extension cord.
Examine the cord before each use and replace it if
necessary. Do not abuse an extension cord. Pull
on the plug, not the cord, to disconnect it. Keep
the extension cord away from hot surfaces and
sharp edges.
GROUNDING INSTRUCTIONS
CIRCUIT BREAKER INSTRUCTIONS
The Wheatgrass Juicer is equipped with a
Circuit Breaker to protect it from damage due
to overload or short circuit. If the Wheatgrass
Juicer should unexpectedly stop running, take
the following steps to get it running again.
1. Turn the Power Switch to the “OFF”
position.
2. Check for possible reasons for the overload,
ie. a jam in the machine or incorrect assembly.
3. Press the Circuit Breaker Reset Button (Figure 1).
4. Turn the Wheatgrass Juicer back on and resume juicing.
5. Resume normal operation.
If the Wheatgrass Juicer still does not run, check the household circuit breaker to see if it
has tripped and/or try connecting the Power Cord to a different electrical outlet. If these steps
don’t work or if the Circuit Breaker repeatedly trips, turn the unit off and disconnect it from the
electrical outlet. DO NOT continue to try running the Wheatgrass Juice or unit damage
may occur. Contact Pragotrade at the number on the back of this manual for information on unit
repair or replacement.
Figure A
3 prong
grounding-
type plug
Figure C
Metal
Grounding
Screw
Cover of
Grounded
Outlet Box
Figure B
Grounding
Plug
Aadaptor
Metal tab or
wire
-9-
ALLOW MOTOR TO
COMPLETELY STOP BEFORE ENGAGING IN
FORWARD OR REVERSE.
READ & FULLY UNDERSTAND ALL INSTRUCTIONS AND WARNINGS PRIOR TO USING THIS UNIT.
Figure 1
Circuit Breaker
Reset Button
NOTICE: DO NOT run the Wheatgrass
Juicer in reverse for more than 3 seconds
at a time. Unit damage may occur.
Use the
Reverse Function to improve
flow through the Wheatgrass Juicer when
necessary. Briefly engage “Reverse” to help
clear a jam, for example.
1. Turn the Power Switch to the “OFF” position.
2. Wait until the Juicer Motor comes to a
complete stop.
3. Briefly hold the Power Switch in the “Reverse” position (Figure 8). DO NOT hold the Power
Switch in “Reverse” for more than about 3 seconds. Unit damage may occur.
4. The
Power Switch will automatically return to “OFF” once released from the “Reverse”
position.
If juice flow does not improve after engaging “Reverse” , disassemble, clear the jam and
clean the Screen holes before resuming operation.
USING THE REVERSE FUNCTION
WASTE VALVE SETTINGS
To extract the maximum amount
of juice from wheatgrass, we
recommend you fully close the
Waste Valve (Figure 7). A different
setting may result in more juice,
though. Experiment by adjusting the
Waste Valve in and out. Be careful
not to remove the Waste Valve while
the Wheatgrass Juicer is running.
ALLOW MOTOR TO
COMPLETELY STOP
BEFORE ENGAGING IN FORWARD OR REVERSE.
READ & FULLY UNDERSTAND ALL INSTRUCTIONS AND WARNINGS PRIOR TO USING THIS UNIT.
NEVER operate Wheatgrass Juicer unless it is
fully and properly assembled.
To avoid serious or fatal injury, NEVER reach into any inlet or outlet.
ONLY USE the Stomper to push wheatgrass into the Head.
Read and understand all information in this manual before use.
WARNING!
WARNING!
Before cleaning, assembling or disassembling the
Wheatgrass Juicer, make sure it is turned “OFF” and the Power Cord is
disconnected from the electrical outlet.
Power
Switch
Figure 8
Figure 7
Waste
Valve
