9.Presser Foot Lift Parts
-42-
Item Part number Description P cs
Sliding block rail
Screw
Screw
Nut
Screw
Spring
Knee lift lever
Pressure adjusting screw
Pressure bar spring lever
Screw
Screw
Knee control crank assembly
Knee lift prop rod
Split pin
Stop collar
Screw
Presser foot
Set screw
Bushing for presser bar shaft
Springy lever holder
Screw
Presser foot lift lever
Screw
Thread releasing lever
Presser bar guide
Tension screw
Presser bar
Screw
Spring
Magnet
Oil reservoir
Oil gasket
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
1WF5-040
1WF5-039
1WF3-011
1WF3-010
1WF3-013
1WF3-014
1WF3-012
1WF3-015
1WF3-016
1WF3-018
1WF3-017
1WF3-019
1WF3-021
1WF3-020
1WF3-024
1WF3-025
1WF3-001(9WF3-001)
1WF3-002
1WF3-004
1WF3-005
1WF2-006
1WF3-023
1WF3-022
1WF3-007
1WF3-008
1WF3-009
1WF3-003
1WF3-023
1WF3-006
22F9-012
58F0-001A1
58F0-001
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
1
1
1
