3. Upper Shaft Presser Foot Parts
-20-
Item Part number
Upper shaft
Front bushing
Screw
Oil felt
Needle crank
Screw
Screw
Screw
Screw
Presser foot lift eccentric cam
Stop ring
Slot for front crank sliding block
Stop ring
Screw
Set screw
Ball bearing for upper shaft
Rear bushing for upper shaft
Screw
Balance wheel
Screw
Teeth belt
Spring plate
Pin for eccentric shaft
Spring
Split stop ring
Stop plate
Nail
Control plate
Connection
Bushing
Set screw
Description P cs
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19..
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
1WF2-025
1WF2-022
1WF2-023
1WF2-024
1WF2-021
1WF2-020
1WF2-007
1WF2-010
1WF2-009
1WF5-026
1WF5-041
1WF2-026
1WF2-030
1WF2-029
1WF2-031
1WF2-019
1WF2-032
1WF2-044
1WF2-028
1WF2-039
1WF2-037
1WF2-041
1WF2-040
1WF2-048
1WF2-045
1WF2-042
1WF2-046
1WF2-047
1
1
1
1
1
1
1
3
1
1
1
1
3
3
1
1
1
2
1
2
1
1
1
1
1
1
1
1
1
1
1
