DXZ735MP
17
English
16
DXZ735MP
English
CD/MP3/WMA Operations
CAUTION
When the unit enters the CD/MP3/WMA mode,
play starts automatically.
If there is no disc loaded, the indication “ NO
DISC” appears in the title display.
∗ The mode changes each time the [FNC] button is
pressed. (Modes are not displayed for equipment
that is not connected.)
2. After making these settings, remove the disc
and then reinsert it.
3. When a mixed mode CD is loaded and CD is
set, the track to be played first is MP3/WMA
file data and no sound is heard.
Disc-In-Play function
As long as the ignition key is turned to the ON or
ACC position, this function allows you to turn the
power to the unit and start playing the disc auto-
matically when the disc is inserted even if the
power is not turned on.
Set to MP3/WMA Disc
Mixed with CD and
MP3/WMA type tracks
CD type track only
MP3/WMA type track only
Set to CD
Play CD
Play MP3/WMA
Setting
Play CD Play CD
Play MP3/WMA
Play MP3/WMA
Radio CD/MP3/WMA
(CD changer)
(MD changer)
(DVD changer) AUX (TV)
• Do not try to put your hand or fingers in the
disc insertion slot. Also never insert for-
eign objects into the slot.
• Do not insert discs where adhesive comes
out from cellophane tape or a rental CD la-
bel, or discs with marks where cellophane
tape or rental CD labels were removed. It
may be impossible to extract these discs
from the unit and they may cause the unit
to break down.
Backup Eject function
Just pressing the [ Q] button ejects the disc
even if the power to the unit was not turned on.
1. Press the [OPEN] button to open the FLIP
DOWN PANEL.
Note:
• If the FLIP DOWN PANEL will not open far
enough, open it gently with your hand.
2. Press the [ Q]button. Remove the disc after it
is ejected.
3. Close the FLIP DOWN PANEL.
Note:
• Always close the FLIP DOWN PANEL once you
take out the disc.
Listening to a disc already loaded
in the unit
Press the [FNC] button to select the CD/MP3/
WMA mode.
Loading a CD
1. Press the [OPEN] button to access the CD
SLOT behind the FLIP DOWN PANEL.
2. Insert a CD into the center of the CD SLOT
with the label side facing up. The CD plays
automatically after loading.
Notes:
• Never insert foreign objects into the CD SLOT.
• If the CD is not inserted easily, there may be another
CD in the mechanism or the unit may require service.
• Discs not bearing the or mark and
CD-ROMs cannot be played by this unit.
• Some CDs recorded in CD-R/CD-RW mode may
not be usable.
Loading 8 cm compact discs
∗ No adapter is required to play an 8 cm CD.
∗ Insert the 8 cm CD into the center of the insertion slot.
3. Close the FLIP DOWN PANEL.
Be careful not to catch your hand or fingers
while closing the FLIP DOWN PANEL.
CAUTION
Notes:
• If the FLIP DOWN PANEL does not open fully,
gently open with your hand.
• After loading a CD, always close the FLIP DOWN
PANEL.
Pausing play
1. Press the [ ] button to pause play.
“PAUSE” appears in the display.
2. To resume CD play, press the [ ] button
again.
CD/MP3/WMA Operations
2. Files without MP3/WMA data will not play.
The indication “––:––” appears in the play
time display if you attempt to play files with-
out MP3/WMA data.
● Logical format (File system)
1. When writing MP3/WMA file on a CD-R disc
or CD-RW disc, please select “ISO9660 level
1, 2, 3 or JOLIET or Romeo” as the writing
software format. Normal play may not be pos-
sible if the disc is recorded on another format.
2. The folder name and file name can be dis-
played as the title during MP3/WMA play but
the title must be within 128 single byte alpha-
betical letters and numerals (including an ex-
tension).
3. Do not affix a name to a file inside a folder
having the same name.
● Folder structure
1. A disc with a folder having more than 8 hier-
archical levels will be impossible.
● Number of files or folders
1. Up to 255 files can be recognized per folder.
Up to 500 files can be played.
2. Tracks are played in the order that they were
recorded onto a disc. (Tracks might not always
be played in the order displayed on the PC.)
3. Some noise may occur depending on the type
of encoder software used while recording.
Multisession function
When a disc contains both normal CD type tracks
and MP3/WMA type tracks mixedly, you can se-
lect which type of the recorded tracks to play.
● Default value is “CD”.
Each time you press and hold the [BND] button
for about 1 second, the mixed mode is switched
between CD type or MP3/WMA type. The follow-
ing indication appears in the title display when
switching the track type to be played.
● Display when CD type track is selected:
MP3/WMA
What is MP3?
MP3 is an audio compression method and clas-
sified into audio layer 3 of MPEG standards.
This audio compression method has penetrated
into PC users and become a standard format.
This MP3 features the original audio data com-
pression to about 10 percent of its initial size
with a high sound quality. This means that about
10 music CDs can be recorded on a CD-R disc
or CD-RW disc to allow a long listening time
without having to change CDs.
What is WMA?
WMA is the abbreviation of Windows Media Au-
dio, an audio file format developed by Microsoft
Corporation.
Notes:
• If you play a file with DRM (Digital Rights Man-
agement) for WMA remaining ON, no audio is
output.
• Windows Media™, and the Windows ® logo are
trademarks, or registered trademarks of Microsoft
Corporation in the United States and/or other
countries.
●To disable DRM (Digital Rights Management):
1. When using Windows Media Player 7, click
on TOOLS ➜ OPTIONS ➜ CD AUDIO;
there, uncheck the ENABLE PERSONAL
RIGHTS MANAGEMENT check box, then
construct files.
2. When using Windows Media Player for Win-
dows XP 8, click on TOOLS ➜ OPTIONS ➜
COPY MUSIC tab, then under COPY SET-
TINGS, unclick the check box for PROTECT
CONTENT. Thereafter, reconstruct files.
Personally constructed WMA files are used
at your own responsibility.
Precautions when creating MP3/WMA disc
● Usable sampling rates and bit rates:
1. MP3: Sampling rate 8k Hz-48 kHz,
Bit rate: 8 kbps-320 kbps / VBR
2. WMA: Bit rate 48 kbps-192 kbps
● File extensions
1. Always add a file extension “.MP3” or “.WMA”
to MP3 or WMA file by using single byte let-
ters. If you add a file extension other than
specified or forget to add the file extension ,
the file cannot be played.
1. Types of recording that can be played are as
follows.
● Display when MP3/WMA type track is se-
lected:
