7 SPECIFIC
ATION
USER MANUAL
TECTON POWER AMP SERIES
P.25
Frequency Response
20 Hz - 20 kHz ± 0,5 dB
8 Ω load, 0 dB below rated power
Input Impedance
4 kΩ balanced
Voltage Gain
selectable: 26 dB, 32 dB, or ,4 V input sensitivity
Protection Circuits
inrush-current limitation, temperature monitoring of transformer and heat-sinks,
output DC protection, power transistor SOA protection, output over current protection,
mains fuses protection
Limiter
switchable clip limiter
Fan
temperature dependent speed-controlled axial fan
Ground Lift
input ground lift switch on back panel
Indicators
LEDs for Mode, Signal, Clip, Output Current and faults for example like DC
Input Connectors
3-pin XLR, male and female per channel, pin 2 = inphase (hot)
Output Connectors
one 4-pole SPEAKON connector for each output channel (bi-amping possible)
Modes of Operation
Stereo, Mono-Bridge and Parallel-Mono
Options
Extended User Interface / E.U.I. 2 – modules for any kind of EQ
THD+N (typical)
< 0,0 %
20 Hz - 0 kHz, 8 Ω load,
0 dB below rated power
SMPTE (typical)
< 0,0 %
8 Ω load,
0 dB below rated power
Damping Factor
> 400
8 Ω load, kHz and below
Dimensions (WxHxD)
483 x 88,9 x 330,7 mm (9”, 2U)
Net Weight
9,4 kg
Shipping Dimensions (WxHxD)
540 x 35 x 540 mm (0,04 m
3
)
Shipping Weight
kg
Subject to technical alterations without prior notice
