USER MANUAL
TECTON POWER AMP SERIES P.0
2.3 Factory Settings
TECTON amplifiers are delivered with the following factory settings
Front panel:
On/Off Switch Off Amplifier is switched off
2 Volume Control - Channel B Off
3 Volume Control - Channel A Off
Rear panel:
7 Input Ground Lift
Grounded
8 High Pass Filter channel B Off
9 Mode Selector Stereo
20 Gain Selector 26 dB
2 High Pass Filter channel A Off
22 Clip Limiter Off
Make sure that the switches are set to the configuration needed for each par-
ticular application. For more detailed information, see sections 3.5, 3.7 and 4.1.
