PS Engineering
PMA6000 Series Audio Selector Panel and Intercom System
Installation Manual
200-066-0006 Page 1-4 Rev. 6, March 2005
1.6 EQUIPMENT SUPPLIED
A. 1 ea. of the following units:
Model Part Number
PMA6000 6000
PMA6000S 6000S
PMA6000M 6000M
PMA6000M-S 6000MS
PMA6000C 6000C
PMA6000S-C 6000SC
PMA6000M-C 6000MC
PMA6000M-S-C 6000MSC
Tray
430-004-0001
B. PMA6000 Installation Kit:
Part Number Description Quantity
Stereo
Quantity
Mono
120-425-4402 Top Connector, Stereo (key 4/5) 1 x
120-425-4401 Top Connector, Mono (key 2/3) x 1
120-425-4400 Bottom Connector (key 7/8) 1 1
425-001-0001 Gold Plated Crimp Pins 75 75
701-015-0015 15 Watt Dropping Resistor
(Recommended for 28 Volt Systems) 1 1
200-066-0003 Operator's and Installation Manual 1 1
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
A. Speaker, 4
Ω
B. Headphones, 150
Ω stereo (6000S) or mono (6000), up to 6 as required
C. Microphones, up to 6 as required
D. Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed)
E. Interconnect Wiring
F. Headphone Jacks (As Required)
G. Microphone Jacks (As Required)
H. Circuit Breaker: 1 ea. 2 amp.
1.8 LICENSE REQUIREMENTS
None
