PS Engineering
PCD7100 Series Intercom System with Integral Music System
Installation and Operator’s Manual
200-971-0006
Page 1-3
Rev. 8, Jan. 2015
1.6
EQUIPMENT SUPPLIED
1 ea. of the following units:
Model
Part Number
Description
PCD7100-I
11950
CD w/6-place ICS
PCD7100-I
11951
CD w/6-place ICS w/IRS
PCD7100-P
11952
CD only
PCD7100-P
11953
CD only w/AWS
PCD7100-P
11954
CD/MP3 Player Only w/Audio Warning System
PCD7100-I
11956
CD/MP3 Player w/6-place ICS
PCD7100-I
11957
CD/MP3 Player w/6-place ICS and /Internal Recorder
PCD7100-P
11958
CD/MP3 Player only
PCD7100 Installation Kit: 250-971-0001 or 250-972-0400 as shown
Part Number
Description
250-971-0001
Unit Part Number
11950, 11951, 11953,
11954, 11956, 11957
250-972-0400
Unit Part Number
11952, 11958
120-430-9701
Tray
1
1
120-425-4402
44 Pin Connector Key 4/5
1
1
425-001-0002
Gold Plated Crimp Pins
35
10
475-440-0007
4-40x7/16" Phil-Pan w/Nylon
Patch
2
2
475-630-0002
6-32 Clip Nut
6
6
475-632-0012
6-32 x ½ Phil screw
6
6
200-971-00XX
Operator's and Installation
Manual
1
1
1.7
EQUIPMENT REQUIRED BUT NOT SUPPLIED
a)
Circuit Breaker, PULL TYPE: 1 ea. 3 amp (11950, 11951, 11954, 11956, 11957) or 2 amp
(11952, 11953, 11958)
b)
Headphone Jacks (Stereo, up to 6 as required)
c)
Microphone Jacks (up to 6 as required)
d)
Headphones, 150
(Stereo), up to 6 as required
e)
Microphones, up to 6 as required
f)
Interconnect Wiring
g)
Intercom or audio system (11952, 11958, 11953, 11954)
1.8
LICENSE REQUIREMENTS
None
