Page 10 200-193-0005 Rev. 8, Nov. 2013
PM3000 (11932, 11934) w/Crew, 6-place wiring diagram
Notes:
1. All wire must conform to MIL-22759 or 27500. Minimum 24 gage shielded wire.
2. Use 2-, and 3-, conductor with shield as indicated.
3. Use insulating washers on all jacks. Jacks must be electrically floating.
4. Connect shields at intercom end only
5. AUX headphone and microphone jacks are required.
6. For 11931 and 11933, do not connect passenger 3 & 4, or Music 2 inputs.
Copilot Phone Audio (L)
Copilot Phone Audio (R)
Copilot Phone Audio Lo 21
8
20
7
1A
11-33 VDC 13
1
14
PM3000 Sub-D DB-25 Male
Pass 1 Mic
Power In
Ground
AUX Headphone
Jack
A/C PTT
A/C Mic Audio Hi
A/C Mic Audio Lo
To Aircraft Radio Mic Audio Lo
To Aircraft Radio
Phone Low
12
25
Aircraft Radio PTT
To A/C Radio Mic Audio Hi
Aux Mic Jack
To Aircraft Radio
Phone Audio Hi
Pilot Headphone Jack
22
9 Pilot Phones (L)
Pilot Phones (R)
Pilot Phones Lo
Copilot Headphone Jack
Passenger 1
Headphone
Pass 2 & 4 Phones Audio (L)
Pass 2 & 4 Phones Audio (R)
Pass Phones Audio Lo
19
6
Pass 1 Mic Audio Hi
Pass 1 Mic Audio Lo 15
Pass 2 Mic Pass 2 Mic Audio Hi
Pass 2 Mic Audio Lo 2
Pilot Mic Jack
Copilot Mic Jack
10
23
Pilot PTT
Pilot Mic PTT
Pilot Mic Audio Hi
Pilot Mic Audio Lo
Copilot PTT
Copilot Mic PTT
Copilot Mic Audio Hi
Mic Audio Lo 16
3
Entertainment #1 Input
24
11 Music #1 (L)
Music #1 (R)
NOTES:
Passenger 3
Headphone
Passenger 2
Headphone Passenger 4
Headphone
Pass 3 Mic
Pass 3 Mic Audio Hi
Pass 3 Mic Audio Lo 5
Pass 4 Mic Pass 4 Mic Audio Hi
Pass 4 Mic Audio Lo 18
17
4 Music #2 (L)
Music #2 (R)
Entertainment #2 Input
SEE NOTE 6
SEE NOTE 6
SEE NOTE 6
A/C Radio Phone Audio Hi
A/C Radio Phone Audio Lo
Pass 1 & 3 Phone Audio (L)
Pass 1 & 3 Phone Audio (R)
Pass 1 Phone Audio Lo
