SUPER NODE™ USER MANUAL
21
Figure 9: Super Node Dimensions
11.02"
3.38"
12.55"
SUPER NODE
MODEL 20-9821-0001
LINK
ACT
LINK
ACT
DMX
RDM
DMX
RDM
DMX IN
RDM IN
REAR
INPUT
1
2
DMX
RDM
3
DMX
RDM
4
DMX
RDM
5
DMX
RDM
6
DMX
RDM
7
DMX
RDM
8
DMX OUT
CONSOLE IN
19.00"
3.44"
FRONT VIEW
SIDE VIEW
TOP VIEW
