SoundMax SM-CMD3007 - Manual (Page 31)

31
Specification
General
Power supply:
12 V DC
Maximum power output: 4 x 50 W
Storage support: DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW/USB/SD/MMC
Compatible formats: DVD/DVCD/SVCD/VCD/HDCD/MP3/CDDA/Picture-CD/Photo-
CD/JPEG/MPEG4 (DivX)
Unit dimensions/Net weight: 170 x 178 x 50 mm/1.55 kg
Gift box dimensions/Gross weight: 235 x 285 x 103 mm/2.25 kg
ESP function:
40 sec. for Audio CD, 120 sec. for MP3
Temperature range: -20 0 C - +60 0 C
TFT display
Screen size:
3 inches
Resolution: 240 TV lines
Aspect ratio: 16:9
Contrast ratio: 400:1
Brightness: 250 cd/m 2
View angle: V: 120 0 , H: 120 0
FM Radio
Frequency range:
65.0 – 74.0/87.5 – 108.0 MHz
Usable sensitivity: <15 dB
Preset memory stations: 18
AM Radio
Frequency range:
522 kHz - 1620 kHz
Preset memory stations: 6
Specifications are subject to change without notice. Mass and dimensions are approximate.
