GFX-15 Amplifier

Crate continually develops new products, as well as improves existing ones. For this reason, the

specifications and information in this Crate manual are subject to change without notice.

Output Power Rating

12 watts RMS @ 5% THD 4 ohms, 120VAC

Gain, Overdrive Channel

86dB +/-6dB @ 1kHz

Gain, Clean Channel

46dB +/-6dB @ 1kHz

Tone Control Range, Low

25dB @ 80Hz

Tone Control Range, Mid

19dB @ 900Hz

Tone Control Range, High

23dB @ 5kHz

Signal To Noise, Overdrive Channel

>50dB

Signal To Noise, Clean Channel

>65dB

Maximum Signal Accepted

2.2 volts RMS min. @ 400Hz

Internal Speaker

8” Crate Custom Design 4 ohm

Input Power Requirements

120 VAC, 60Hz, 30VA
100/115VAC, 50/60Hz, 30VA
230VAC, 50/60Hz, 30VA

Size and Weight:

13” H x 13.63” W x 8.25” D, 15 lbs.

The GFX-15 is covered with a durable black Tolex material: wipe it

clean with a lint-free cloth. Never spray cleaning agents onto the

cabinet. Avoid abrasive cleansers which could damage the finish.

GFX-15 TECHNICAL SPECIFICATIONS

Declaration Of Conformity

#33, Effective 01-01-2001

Manufacturer’s Name:

SLM Electronics

Production Facility:

11880 Borman Drive, St. Louis, MO 63146, USA

Production Facility:

700 Hwy 202 W, Yellville, AR 72687, USA

Shipping Facility:

1400 Ferguson Ave., St. Louis, MO 63133, USA

Office Facility:

1400 Ferguson Ave., St. Louis, MO 63133, USA

Product Type:

Audio Amplifier

Complies with Standards:

LVD:

92/31/EEC, 93/68/EEC, & 73/23/EWG

Safety:

EN60065

EMC:

EN55013, EN55020, EN55022, EN61000-3-2,
& EN61000-3-3

Supplementary information provided by your local Sales & Services Office or:

SLM Electronics - R & D Engineering

1901 Congressional Drive, St Louis, MO 63146, USA

Tel.: 314-569-0141, Fax: 314-569-0175
