13
72" Fabricated Deck Spindle Assembly - Parts List for Figure 6
Ref.
No. Part No. Description Qty.
1 00005763 Hex Nut, 7/16-14 1
2 00008495 Hex Cap Screw, 3/8-16 x 1-3/4 2
3 00011438 Hex Cap Screw, 3/8-16 x 1-1/2 12
4 00011861 Hex Cap Screw, 3/8-16 x 2-1/2 1
5 00011925 Hex Cap Screw, 3/8-16, 4.00 1
6 00012158 Flat Washer, 3/8 12
7 00022560 Flange Lock Hex Nut, 3/8-16 20
8 00060078 Grease Fitting, 1/4-28 x 3/16 2
9 00083192 Idler Washer 1
10 01000302 Shoulder Screw, 7/16-14 1
11 01000364 Hex Carriage Screw, 3/8-16, 1.75 1
12 01000380 Flange Hex Nut, 3/4-16 3
13 01000387 Torsion Idler Spring 1
14 01000389 Lock Washer, 7/16 1
15 01000393 Flat Washer, .469 ID, .875 OD, .105 1
16 01000643 Carriage Bolt, 3/8-16 x 1 3
17 01000723 Flat Washer, .406 ID, 1.0 OD, .105 6
18 01002564 Spacer, .76 ID x 2.0 OD x .477 1
19 01002751 Spacer, .39 ID x .63 OD x 1.75 1
20 01002771 Cotter Pin, .072 x 1.12 Long 2
21 01003123 Spacer .812 ID x .268 LG 3
22 01003245 Spacer, .39 ID x .625 OD x 2.75 1
23 01004081 Flat Pulley 1
24 01004101 Idler Pulley, 4.06 OD 1
25 01005434 Aluminum Spindle Support Plate 3
26 01007499 V-Pulley, 5.75 OD 3
27 01007786 Idler Arm Assembly, Deck 1
01000308 Bearing Sleeve 2
28 01007937 V-Belt, B Section x 124.0 LG 1
29 01008018 Spacer, .760 ID x 2.00 OD x .330 3
30 01008618 Tension Idler U-Bracket 1
31 01008252 Handle Tension Weldment 1
32 01008270 Tension Idler Handle Grip 1
33 01008542 Hex Cap Screw, 3/4-16, 7.50 2
34 01008543 Hex Cap Screw, 3/4-16, 9.50 1
35 02000568 Bahia Blade, 25.0, .756 ID 3
36 02000583 V-Pulley, 6.95 OD x .750 Bore, Cast 1
37 02000611 V-Belt, B Section x 155 LG 1
38 02000726 Extension Spring, 1.0 x OD x 5.00 1
39 02000920 Aluminum Spindle Assembly 3
40 02001574 Spring Tension Rod 1
41 02003489 Idler Arm Assembly includes: 1
01000308 Bearing Sleeve 2
42 02004064 Adaptor Plate 1
43 756-3045 Idler Pulley, 5.06 Dia. 1
