20
Section VI Appendix (Continued)
Fig. 2. Microphone Cable Preparation
To wire the microphone cable to the plug provided, proceed as follows.
Fig. 3. Microphone plug wiring.
1. Remove the retaining screw.
2. Unscrew the housing from the pin receptacle body.
3. Loosen the two cable clamp retainer screws.
4. Feed the microphone cable through the housing, knurled ring and washer as
shown Fig. 3B.
5. The wires must now be soldered to the pins as indicated in the above wiring tables.
If a vise or clamping tool is available it should be used to hold the pin receptacle
body during the soldering operation, so that both hands are free to perform the
soldering. If a vise or clamping tool is not available, the pin receptacle body can
be held in a stationary position by inserting it into the microphone jack on the front
panel. The numbers of the pins of the microphone plug are shown in Fig 4, as
viewed from the back of the plug. Before soldering the wire to the pins, pre-tin the
wire receptacle of each pin of the plug.
