PSoC Express

TM

PSoC Express is the first visual embedded system design tool that allows a user to create an entire
PSoC project and generate a schematic, BOM, and data sheet without writing a single line of code.


Users work directly with application
objects such as LEDs, switches, sensors,
and fans.

For more information and to download
Express, please visit

www.cypress.com/express


Select inputs and outputs

Define the output’s behavior

Simulate the design to verify

Build to generate PSoC HEX file, BOM, schematic, and custom data sheets of your design
Optimize your design with monitoring and tuning functions

Compilers

Currently there are two C compilers offered with PSoC Designer

TM

:

IMAGEcraft

TM

HI-TECH

TM

C PRO for PSoC Mixed Signal Arrays


ANSI C compiler

Inline assembly and interface with
assembly modules

Modern stack-based architecture

7 basic data types including IEEE 32-bit
floating point

Assembler and linker

Math and string libraries

‘C’ interrupt service routines

• Librarian







Price: $145 (MSRP)

www.cypress.com/go/imagecraft


ANSI C compiler

Eliminates the need for many non-standard C
qualifiers and compiler options

Automatically analyzes user assembly and
object code files as a whole, with Omniscient
Code Generation
™ technology

Memory banking without requiring special
qualifiers for better performance

Optimizes the size of each pointer variable

• Eliminates

contention for the PSoC index

register

Produces more efficient interrupt context
switching code

• Customizes

the

functionality of the printf

library function for maximum efficiency

Delivers Denser Code For Better Performance
- Up to 50% more compact code than others!


Price: $1495 (MSRP)

www.cypress.com/hitech
