3. WLAN Configuration Settings
To change any of these settings:
1. Double click on the Wireless Status icon in the system tray to change your wireless LAN
settings or to view current link information.
2. Modify the wireless LAN setting in the wireless LAN configuration utility to successfully
connect to your wireless network.
3. Click on Apply to activate the modified WLAN settings.
For more information on Wireless LAN settings and configurations, please refer to the online user's
guide contained on the CD included with your WL100 PC card.
4. Release Notes
This version of the WL100 drivers for Windows CE 3.0 will run on PocketPCs or handheld devices
equipped with most commonly used processors, such as:
■ SH3
■ SH4
■ MIPS
■ ARM / STRONGARM
The initial WLAN configuration settings after the driver installation are:
Field Value
SSID COMPAQ
Network Type Infrastructure
Tx Rate Auto
DS Channel 6
WEP Disabled
