Introduction

37

Nothing Comes Close to a Cobra

®

Specifications

Specifications

36 English

Specifications

General

Number of Channels

All U.S., Canadian, International and
NOAA Weather Channels

Channel Spacing

25 kHz

Modulation

5 kHz Max.

Input Voltage

7.4 VDC

Battery Life:

LiON: 8 hours @ 6 watts,

5% TX, 5% RX, 90% Standby

16 hours @ 1 watt
Alkaline: 18 hours @ 6 watts,
35 hours @ 1 watt

Current Drain:

Standby

40 mA

Receive (Rx)

200 mA

Transmit (Tx)

1.8 A @ High Power, 700 mA @ Low Power

Temperature Range

-20˚C to 50˚C

Radio Dimensions

4.8" x 2.4" x 1.4"
(123 mm x 62 mm x 36 mm) not
including antenna

Radio Weight

0 lbs 8 oz. (228 g) without batteries

Receiver

Frequency Range

156.050 to 163.275 MHz

Receiver Type

Double Conversion Super-Heterodyne

Sensitivity:

20 dB Quieting

0.35 uV

12 dB Sinad

0.30 uV

Adjacent Channel Selectivity

-60 dB

Intermodulation and Rejection

-60 dB

Spurious and Image Rejection

-60 dB

AF Output

250 mW @ 8 Ohms

Transmitter

Frequency Range (Tx):

156.025 to 157.425 MHz

RF Output Power

1, 3 or 6 watts (5 maximum in Australia)

Spurious Emissions

-60 dB @ High Power, -55 dB @ Low
Power

Microphone Type

Condenser

Frequency Stability

+/-10 ppm

FM Hum and Noise

40 dB

VHF Marine Radio Protocols

Emergency Messages
and Distress Procedure

For Example

“Mayday — Mayday — Mayday”

“This is Corsair — Corsair — Corsair” [repeated three (3) times]

“Mayday Corsair”

“Point Lynas bears 220 degrees magnetic — distance 5 kilometers”

“Struck submerged object and flooding — need pump and tow”

“Four (4) adults, three (3) children aboard — no one injured”

“Estimate we will remain afloat one-half hour”

“Corsair is 8 metre sloop with blue hull and tan deck house”

“I will be listening on Channel 16”

“This is Corsair”

“Over”

VHF Marine Radio Protocols
