17
OPTIONS PROGRAMMING
To Engage Option Programming:
1. Open hood (If no hood pin switch is installed, then ground the Gray wire)
2. Turn Key to the ON position. (Do not start vehicle) Pink wire must be connected!
3. Press the program / valet button 5 times. Wait for the unit to flash the lights and/or horn honk 5 times.
4. Push the valet/program button the number of times that corresponds to the option number desired (1-22X). You
must get a light flash and/or honk after each button press. If the system did not flash the lights and/or honk, then it
did not register your press. Press carefully and do not lose count.
5. A) For RS1300/1/3/4DP or 1604TW1/1704TW2/1804FM: When you reach the desired option #, Press button
#1(Lock) or #2 (Unlock) to change the option. (Some option numbers use ALL 4 remote buttons to select settings)
5. B) For RS-1300DP: (No remotes) Tap the brake pedal to toggle through the option values: Tap the brake once
(lights flash 1X; Tap the brake pedal again (Lights flash 2X) tap 3 or 4 times for options that have 3 or 4 values.
6. When finished, turn Ignition OFF, close hood (or un-ground Gray wire) and check for changed features.
* = Default Value
Option
#
Option Description Option Values Button #1
LOCK
Button #2
UNLOCK
1. Engine Monitoring Tach (Engine RPM) or Tachless Tach Tachless*
2. Autolock with RPM/Ignition ON (RPM/Ignition) or OFF. ON *OFF
3. Door Lock Pulse Time 0.75 Sec. (Standard) OR
3.0 Sec. (European Vacuum) 3 Sec. *0.75 Sec.
4. Double Unlock Pulse Single or Double Unlock Pulse Double *Single
5. OEM Interface
(RS1300 MODEL ONLY) Remote Start w/Single Pulse or
3 Pulses on Green input wire 3 pulse *1 Pulse
6. Double button press for remote
start and Trunk release ON or OFF ON *OFF
7. Horn Chirps on remote start ON or OFF ON *OFF
8. Lock During and After
Remote Start Abort ON or OFF OFF *ON
9. Tan Wire Output function Trunk or Dome Light Output Dome *Trunk
10. “Wake up” Pulse on Unlock
(1-sec +12V to IGN) ON or OFF ON *OFF
