Casio LK230ES1A - Manual (Page 16)

Controlling the Keyboard Sounds
E-14
5.
Output the sound from the microphone.
The Digital Keyboard will start sampling automatically,
and stop after one second.
What you sample is stored as tone number 401.
6.
Try playing something on the keyboard.
• You can press pad 4 or 5 ( cl or cm ) to sound the
sampled sound (page E-9).
• Sampling will not start if the volume of the sound picked up
by the microphone is too low.
• A new sample replaces sample data currently assigned to
tone number 401. All of the old data (including short
sampled sounds) is deleted.
■ Short Sampling
With short sampling, you can sample up to three sounds,
each one with a duration of approximately 0.3 seconds. You
can sound the short sampled sounds using voice pads
1 through 3.
1.
Connect a microphone to the keyboard.
Refer to steps 1 through 3 under “Full Sampling” (page
E-13).
2.
While holding down 5 , press the voice pad ( bs ,
bt , or ck ) that corresponds to the tone number
where you want to store the sound.
• The relationship between tone numbers and voice pads
is shown below.
Example: When voice pad 3 (Tone Number 404) is
selected
Record standby is entered when you release 5 .
3.
Output the sound from the microphone.
Sampling starts automatically and stops after about 0.3
seconds.
4.
Try playing something on the keyboard.
You also can sound the sampled sound by pressing the
voice pad you pressed in step 2.
• Sampling will not start if the volume of the sound picked up
by the microphone is too low.
• Sampling a new sound deletes the sound assigned to the
same tone number and the full sampling sound (page
E-13).
S a m
p
l i n
g
O r i
g
i n a l
Flashes
Lights
Selected Tone
Number
402 403 404
Pressed Voice Pad Pad 1 ( bs ) Pad 2 ( bt ) Pad 3 ( ck )
V o i . P a d 3
Flashes
W a i t i n
g
Flashes
V o i . P a d 3
Lights
