4.
a
Fig. 1 Capresso EC50 User Components
a. Removable Cup Warming Tray
b. Removable Water Tank
c. Steam Wand
d. Black Frothing Sleeve (removable)
e. On/Off Switch
f. Removable Drip Tray
g. Removable Grid
h. Portafilter
i.
Thumb Guard
j. Brew Head (with Screen and
Center Screw)
k. Selector Dial (Coffee /Steam)
l.
Steam Symbol
m. Coffee Symbol
n. Ready indicator
p. Measuring Scoop with Tamper (not
shown)
Steam Wand (remove Black Frothing
Sleeve) for steaming only Align bump on sieve with notch in
the portafilter. Insert and twist.
Dual function sieve (for 1 or 2 cups)
bump
notch
Fig. 2
Fig. 3
Fig. 4
b
d
e
l
k
n
m
h
g
f
j
i
c
