Specification – Hyundai H-CMD7082 User Manual
Page 41
41
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General.
Power supply:
12 V DC (11 V 16 V)
Current consumption:
15 A
Maximum power output:
50 W x 4 channels
Dimensions (W x H x D)
178 x 50 x 166 mm
Working temperature range:
-10º - +60º
FM Stereo Radio.
Frequency range:
65.0 74.0/87.5 - 108.0 MHz
Usable sensitivity:
8 dB
MW Section.
Frequency range:
522 kHz-1620 kHz
DVD Deck Specification
Format
DVD/ DVD±R/ SVCD/ VCD/ CD/ MP4/ MP3/ WMA/ CD-R/RW
Video System/ Audio System
Standard NTSC/PAL/AUTO / 24 bit/96 KHz
Loading System
Auto Loading
Mounting Angle
0 to +/-30
Video Specification
Video System
16:9 and 4:3
Video Output level
1.0 Vp-p 75 ohms
Audio Specification
Maximum Output
2 Vrms (+/- 3 dB)
Frequency Response
20 to 20 KHz
S/N Ratio(A-vtd)/ Separation
80 dB/ 60 dB
Line out.
Output:
CD max 2000 mV
