The CR-150 HD • 13
Attaching the Declination Slow Motion Knob
Like the R.A. slow motion knob, the DEC slow motion knob allows you to make fine
pointing adjustments in the direction the telescope is pointed.
The DEC slow motion knob attaches in the same manner as the R.A. knob. The shaft
that the DEC slow motion knob fits over is toward the top of the mount, just below
the telescope mounting platform. Once again, you have two shafts to choose from.
Use the shaft that is pointing toward the ground. This makes it easy to reach while
looking through the telescope, something which is quite important when you are
observing.
1. Line up the flat area on the inner portion of the DEC slow motion knob with
the flat area on the DEC shaft.
2. Slide the DEC slow motion knob over the DEC shaft (see figure 2-6).
Figure 2-6 Figure 2-6 Figure 2-6 Figure 2-6 Figure 2-6
