background image

T

TV

V-

-6

60

0/

/1

12

20

0/

/6

62

21

10

0/

/6

62

21

12

2 G

GU

UI

IT

TA

AR

R A

AM

MP

PL

LI

IF

FI

IE

ER

RS

S

TECHNICAL SPECIFICATIONS:

Output Power Rating

TV-60, TV-6210, TV-6212

TV-120

60 watts RMS nominal @ 5% THD

100 watts RMS nominal @ 5% THD

Input Impedance

1M ohm

Ch. 1

Ch. 2

System Gain

74dB

87dB

Tone Controls

Low

16dB range @ 100Hz

Low

8dB range @ 100Hz

Mid

20dB range @ 700Hz

Mid

12dB range @ 1kHz

High

20dB range @ 10kHz

High

14dB range @ 10kHz

Bright

5dB boost @ 5kHz

Boost

8dB boost @ 1kHz

Presence Control

5dB boost @ 10kHz

Effects Send/Return Level

0.7V RMS nominal

Balanced Out Level

0.4V RMS nominal, unloaded

Tube Complement

12AX7 (4), 12AU7 (1), 6L6 GT/5881 (2)

Internal Speaker(s)

TV-60

TV-120

TV-6210

TV-6212

Size and Type

12” Crate 60W (1)

12” Crate 60W (2)

10” Crate 30W (2)

12” Crate 60W (2)

Magnet

38 oz.

38 oz.

30 oz.

30 oz.

Voice Coil

1 3/4”

1 3/4”

1 3/4”

1 3/4”

Impedance

8 ohm

16 ohm

16 ohm

16 ohm

Power Requirements

TV-60, TV-6210, TV-6212

TV-120

120VAC, 60Hz, 110VA

120VAC, 60Hz, 280VA

100/115VAC, 50/60Hz, 110VA

100/115VAC, 50/60Hz, 280VA

230VAC, 50/60Hz, 110VA

230VAC, 50/60Hz, 280VA

Size and Weight

TV-60

TV-120

TV-6210

TV-6212

H x W x D, Inches

18-3/4 x 22-1/4 x 11-1/8

20-1/4 x 26 x 10-1/2

18-3/4 x 22-1/4 x 11-1/8 20-1/4 x 26 x 10-1/2

50 lbs.

70 lbs.

52 lbs.

62 lbs.

The TV-60, 120, 6210 and 6212 are covered with high-quality, durable Tolex

®

. To keep them looking their best, avoid

abrasive cleansers. Wipe the cabinets clean using a slightly dampened soft cloth. Do not spray cleaners directly into

the amplifier. Never use brass cleaners on the hardware since they could damage their protective coatings.

©1997 SLM ELECTRONICS

A DIVISION OF ST. LOUIS MUSIC

1400 FERGUSON AVENUE • ST. LOUIS, MO 63133

P/N 47-584-03 • 07/97

Crate continually develops new products, as well as improves existing ones. For this reason, the specifications and information in this manual are subject to change without notice.
