Coleman 8200 Series - Manual (Page 11)

Fig 38
Fig 39
Fig 40
Igniter Wire
Fig 41
Casting
Side Burner Valve Assy
Fig 42
Casting
Side Burner Valve Assy
Screws
Natural Gas Conversion Instructions
4. Remove the two screws holding the bezel and
valve in place. Remove bezel from the front of
the side burner (Fig. 38).
5. Remove the two screws holding the side
burner LP valve assembly in place. This will
free up the assembly (Fig. 39 & 40).
6. Disconnect the igniter wire from the side burner
electrode (Fig. 40).
7. Holding the assembly securely, remove side
burner valve assembly from casting. Replace
with new side NG side burner valve
assembly (Fig. 41 & 42).
11
