8. INSTALLATIONS

Installation

■

Installation

Note:

• Make sure that the unit is installed securely in place. If the unit is unstable, it may malfunction (eg, the

sound may skip).

■

Installing in Japanese-Made Cars

1. Refer to the section “Removing the hard rubber frame” and then remove the hard rubber frame.

2. Align the holes in the unit (two locations on each side) with the vehicle mounting bracket and secure

the unit with the accessory screws.

Notes:

• During installation, do not use any screws except for those provided. The use of different screws might

result in damage to the main unit.

• Damage may occur if a screwdriver or similar tool is used with excessive force during the installations.

T: Toyota cars
N: Nissan cars

Accessory 3...for Nissan car
Accessory 4...for Toyota car

8 mm
MAX.

ø5mm

8mm
MAX.

T/N

Firewall or metal support

Screw (M4X8)
(commercially available)

Self-tapping screw
(commercially available)

Metal mounting strap
(commercially available)

Bend the tabs of the mounting
sleeve with a screwdriver or
similar utensil and attach it in
place.
