Brightness
•
7700 ANSI lumens maximum
(using 4-lamp mode)
• 3850 ANSI lumens maximum
(using 2-lamp mode)
• 85% brightness uniformity across screen
Contrast Ratio
•
800:1 on/off
Resolution
•
3 x 1.8" p-Si Active Matrix TFT High
Aperture LCD panels
• True XGA 1024 x 768 chip resolution
• 8-bit color resolution offering
16.7 million displayable colors
Dynamic Scaling
•
Digital scaling of VGA – SXGA resolutions
• Digital de-interlacing of STV, DTV and
HDTV formats with Digital Interpolation
Technology (DIT) with a 2:3 pull-down
Horizontal Frequency Range
•
15 to 120kHz
• Automatic frequency control
Vertical Frequency Range
•
50 to 120Hz
• Automatic frequency control
Dot Clock
•
230MHz
Standard Projection Lens
•
A full suite of short/medium/long fixed
and zoom optional lenses
• Fast Lens Change (FLC™) mount has
power adjustable zoom, focus, up/down,
left/right shift
• Lens shift U/D ratio of: 10:0 - 0:10,
L/R 7:3 - 3:7
• Image elevation adjustment: up 5.7 degrees
• Screen size: 40"- 600" (0.15m to
15.24m ) diagonal
Modular Inputs
•
Input 1 (removable): signal – Digital Visual
Interface (DVI-I x 1); audio – RCA x 2
(R, L-mono); control – 8-pin mini-DIN x 1
• Input 2 (removable): signal – BNC x 5
(R,G, B, H, V and Y, Pb/Cb, Pr/Cr); audio –
RCA x 2 (R, L-mono); control – 8-pin
mini-DIN x 1
• Input 3 (removable): signal – BNC x 2
(composite and S-video Y, C); signal –
4-pin MINI-DIN S-video; audio – RCA x 2
(R, L-mono);
• Input 4: signal – analog RGB – D-sub-15 x
1; audio – RCA x 2 (L, R-mono); control –
8-pin min-DIN x 1
Outputs
•
Two built-in 3W speakers (per channel)
and amplifier
• Audio output RCA x 2
Source Compatibility
•
Compatible with VGA, SVGA, XGA,
SXGA, UXGA, MAC, SUN and SGI
computer sources
• Accepts composite video, S-Video and
component video from VCR, DVD, laser
disc players and video cameras
• Auto-detects PAL, PAL M, PAL N, NTSC,
NTSC4.43 and SECAM video standards
• Compatible with DTV/HDTV formats, 480
30i, 480 30p, 720p, 720 60p, 1035 30i,
1080 25i, 1080 30i and 1035i
• HDTV compatible, 800 TV lines
horizontal resolution
• Digital Visual Interface (DVI-D) compatible
Enhanced Feature Set
•
Progressive scan video decoding
• 3-D digital noise reduction
• User-selectable 4 or 2 lamp mode
• Motorized zoom and focus
• Picture freeze function
• ‘No-show’ mode function
• Digital zoom function (min. x1/4, max. x49)
• Digital keystone function (+/- 30 degrees)
• Power management function
• Audio mute
• Presentation timer
Control/Networking
•
Automatic Multi-Scanning Set-up System
(AMSS) (phase/tracking/position)
• USB Type B
• Remote control jack
• RS232-C communications port via
9-pin D-sub terminal (in/out)
• Wired remote control (in/out)
• IR Remote keypad with mouse and
laser pointer
• Front and rear IR receivers
• Remote mouse control
• ChristieNET™ control and monitoring via
HTML and SNMP (optional)
Graphical User Interface
•
Easy set-up and intuitive multi-language
on-screen displays (OSD) (English/German/
French/Spanish/Italian/Portuguese/Dutch/
Swedish/Chinese/Korean/Japanese)
• Direct-key status function
• Choice of image aspect ratios
(4:3 or wide 16:9)
• Blue back display
• Standby on-screen logo display
(30 second duration)
• Picture reverse scans function
(left/right, top/bottom) for front, rear
and inverted projection
Lamp Specification
•
Four 200W UHP lamps
• 1000 hours typical lamp life
• Lamp life warning indicators
• User replaceable lamps
Power Requirements
•
Universal power AC 100 - 240V, 50/60Hz
• Operating voltage: 90 - 264V
(100 - 120V/200 - 240V +/- 10%)
• Power consumption: 1150W maximum
• Thermal dissipation: 3900BTU/hr
• Operating temperature: 0° to 35° C
(storage -15° to 60° C)
• Operating humidity: 20 - 80%
(storage 0 - 90%)
• Acoustic noise level: 45dB (auto fan
control for noise level reduction)
Weight and Size
•
78.2 lbs (35.5 kg)
• 22.9" W x 9.9" H x 32.2" D
• 581.2mm W x 251.5mm H x 783mm D
Standard Accessories
•
Wireless/wired remote controller with
mouse control and laser pointer (two
"AA" type batteries and cable included)
• User manual
• Computer cable (D-sub-15 - D-sub-15)
• MAC/VGA adapter
• Mouse control cable (PS/2, Serial
and MAC)
• DVI cable
• DVI/VGA adapter
• Dust cover
• AC cord x 2 (UL type and European
2P plug type)
Optional Accessories
•
Short throw: 0.8:1, 1.2:1 fixed,
1.3-1.8:1 zoom
• Medium throw: 1.8-2.9:1, 2.6-3.5:1
• Long throw: 3.5-4.6:1, 4.6-6.0:1 zoom,
7.0:1 fixed zoom
• Digital Visual Interface (DVI) module
• 5BNC interface module
• Y/C interface module
• D-sub-15 interface module
• Digital HD-SDI interface module
• SDI serial digital interface module
• 10-bit Faroudja input module
• Lamp module
• Transit case
Regulatory Approvals
•
Complies with all relevant world-wide
EMC and safety standards
• The product complies with FCC Class A,
CE mark and safety requirements IEC950
(EN60950), UL1950 / cUL
Warranty
•
Product warranty 2 years parts and labor
(excluding lamp)
• Lamp warranty 120 days
Reliability
•
Mean time between failure (MTBF) over
19000 hrs
RoadRunner L8
•
Specifications
• The L8 is compatible with a full
array of video and data sources. • 7700 ANSI lumens and the reliability
of a quad lamp system. • Designed for the digital age, the
L8 is equipped with a Digital Visual
Interface to eliminate picture noise
and signal degradation.
