VERVE 5
The Verve 5 is a women’s panel loading technical
hydration pack ideal for shorter duration mountain
biking, trail running and day hiking excursions.
Unique Features
1 Women’s fixed mesh covered perforated EVA foam
BioStretch™ harness providing precise fit and
breathability for increased comfort and performance
2 2L Hydraulics Reservoir included
SPECS ONE SIZE
Cubic Inches 305
Liters 5
Lbs/Ounces 0/15
Kilograms 0.43
Reservoir Wt 11 oz / 0.31 kg
VIPER/VERVE KEY FABRICS
• 210D polyester triple diamond ripstop
• 600D polyester
SHARED FEATURES
Hydraulics™ Reservoir
The reservoir design features a direct welded, anatomically
shaped HydroStatic™ backer plate to prevent barreling of the
reservoir and ensure pack fit is preserved for optimal stability
and comfort This enables the reservoir to conform to the back’s
complex shape, even when full. The result is a more precise,
stable and comfortable fit. Additionally, the reservoir has an
integrated lightweight, low profile handle/spine that stabilizes
the load of the water while also serving as a more convenient
design to slide the reservoir into the pack .
Other Hydraulics™ Reservoir features include:
• Metallocene PE high strength BPA, PVC , taste and odor free material
results in greater reservoir strength and resiliency
• Anti microbial formula to prevent bacteria and mold
• Wide mouth, ¾ turn cap opening provides quick , secure opening
and closing for easy filling and cleaning
• Articulated, 180 degree on/off bite valve with included s
ternum strap magnet
• Access via bite valve to delivery hose for easy cleaning
• Dual side hose exit from the reservoir for easy routing options
• Flexible ¼”/6.35 mm hose provides fast water flow
Inserting/Removing the Hydraulics Reservoir
A Locate and unzip the direct access hydration sleeve
zipper located on the right shoulder harness to gain
entrance to the reservoir compartment. B Grasp
the wide mouth cap attachment loop at the top of the
reservoir and remove. C Use the handle/spine to insert
the reservoir back into the compartment sleeve.
Note: The small, quick release attachment strap is
included as an option to secure other reservoir brands.
Filling the Hydraulics™ Reservoir
Grasp the handle/spine in one hand, undo the wide mouth
cap with the other and fill as desired. Replace the cap
ensuring the gasket is in place and invert to test.
Note: Removing air from the reservoir after filling with
water will help prevent excess slosh. To do this, hold
reservoir upside down, pinch the bite valve and squeeze
the reservoir until all air is expelled.
Customizing The Reservoir Delivery Hose Length
If you find that the delivery hose on your reservoir is too
long or subject to kinking when placed in your pack, follow
these steps:
1 Try reorienting the hose in the pack watching for kinks
as you route the hose through the pack.
2 Try rerouting the hose to the left of the Hydraulics™
wide mouth cap and then curve it back to the right
towards the shoulder harness Hydraulics™ direct
access zipper.
3 Cut the hose to desired length.
To cut the reservoir delivery hose, A Detach the hose from
the reservoir entry point and cut to desired length using
sharp scissors or a utility knife. B Reattach the hose and
invert to test for leaks before using.
TIP: If you have more than one pack you intend to use
your reservoir in, be sure to test the hose routing length
in all before cutting.
Modified AirScape™ Suspension
Every Viper/Verve Series pack features a modified
AirScape™ Suspension consisting of a mesh covered,
molded foam backpanel creating a lightweight,
supportive ventilated pack to back interface.
BioStretch™ Harness
A mesh covered slotted EVA foam gender specific
harness with breathable spacer mesh and direct access
zip to reservoir sleeve creates a soft contact surface
and features a full sternum strap with built-in magnet.
This provides quick bite-valve attachment, allows
flexible, dynamic movement and easy hands free water
management.
Removable Webbing Hipbelt
A removable 20mm webbing hipbelt with fabric
hipwings and modified straight ErgoPull™ closure
keeps the pack stable during dynamic movement.
LidLock™ Helmet Attachment
Every Viper/Verve Series pack features a LidLock™
helmet attachment clip with elasticized load control
system providing quick and secure helmet carry. To use
A locate LidLock™ clip near the top of the pack’s front
panel and pull away from the pack. B In the vertical
position, pass LidLock™ through helmet vent from the
bottom and engage in horizontal position. On the right
outside panel of the pack find a cord loop to increase
or decrease tension. Reverse to remove helmet.
Top Slash Pocket
A quick access top zippered pocket is lined with a
soft, easy to clean heat embossed fabric. Stash your
sunglasses, mp3 player or phone here for scratch
free storage.
Shove-It/Front Panel Pocket
A unique Shove-It pocket for additional storage
features a zippered front panel pocket with internal
mesh compartments and a key clip to keep you
organized during any excursion.
A
B
Blinker Light Attachment
For additional safety a blinker light attachment
patch and reflective graphics are featured on every
Viper/Verve Series pack.
A
A
B
B
A
B
1
2
