OmniSistem PR Chameleon - Manual (Page 2)

Chameleon manual.doc 2/12
SECTION PAGE
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 4
OPERATION 5
XLR CONNECTORS AND TERMINATOR 5
STAND-ALONE MODE 6
MASTER/SLAVE SYNCHRO MODE 6
CONTROLLER MODE - DMX OPERATION 7
MAINTENANCE 9
KEEPING THE PROJECTOR CLEAN 9
TROUBLE SHOOTING 9
TECHNICAL DATA 10
ELECTRICAL DIAGRAM 11
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every apparatus is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the
apparatus is in good condition before your installation and use. Should there be any damage caused by transportation, consult
your dealer and do not use the apparatus. But any damage caused by improper use will not be assumed by the manufacturer
and / or dealer.
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
Mounting Bracket (1 PCS)
M8 knobs for bracket (2 PCS)
Safety cord (1 PCS)
Power-cord (1 PCS)
XLR plug (1 PCS)
XLR socket (1 PCS)
This manual (1 PCS)
Thank you for purchasing our product CHAMELEON, PR-2012H.
CHAMELEON adopts advanced procedure of design and manufacturing and uses international
protocol DMX 512 and complies to CE norms. The outline of housing is elegant, lovable and portable,
which features its special character compared with conventional luminaire. It is convenient to hang the
unit and the angle of the body is easy to be adjusted, and the projector even can be carried by hand.
The unit can be controlled by sound, auto programmes or a controller, and can be used as a stand-
alone unit or linked with each other for multi-units or linked to a controller, so it is suitable for many
different applications.
The lamp brightness can be adjusted and it will be switched off automatically after about 30 seconds
of shutter, so it can effectively prolong the life of the lamp and the projector.
The unit features 8 colourful dichroic filters, and it may produce strobe/shutter and rainbow effect when
the color wheel rotates fast.
The unit has auto thermal cut-off device for the unit operating in a safety condition.
ACCESSORIES
INDEX
INTRODUCTION
