DISPLAY KEY
DISPLAY MODE FUNCTION
ADDR DMX ADDRESS SETTING A001 - A512
CHND CHANNEL MODE 1CH, 3CH, 8CH, 24CH, 28CH
SLND SLAVE MODE MAST, SL1, SL2
SOUN SOUND ACTIVE MODE SOUND ON/OFF
SENE SOUND SENSITIVITY 0-100
BLND BLACK OUT MODE LED MODE, YES - NO
DISP DISPLAY INVERSION INVERTS MENU DISPLAY
TEST TEST MODE SELF TEST
HOUR LIGHT TIME FIXTURE HOURS,0-9999
DMX CONTROL SETTINGS
1 CHANNEL MODE
CHANNEL FUNCTION
CH. 1 000-007 BLACK OUT
008-037 SHOW 1
038-067 SHOW 2
068-097 SHOW 3
098-127 SHOW 4 128-157 SHOW 5
158-187 SHOW 6
188-217 SHOW 7
218-247 SHOW 8
248-255 RANDOM SHOW 1-8
3 CHANNEL MODE
CHANNEL FUNCTION
CH. 1 000-007 MANUAL
008-022 COLOR CHASE 1
023-037 COLOR CHASE 2
038-052 COLOR CHASE 3
053-067 COLOR CHASE 4
068-082 COLOR CHASE 5
083-097 COLOR CHASE 6
098-112 COLOR CHASE 7
113-127 COLOR CHASE 8 128-142 COLOR CHASE 9
143-157 COLOR CHASE 10
158-172 COLOR CHASE 11
173-187 COLOR CHASE 12
188-202 COLOR CHASE 13
203-217 COLOR CHASE 14
218-232 COLOR CHASE 15
233-247 COLOR CHASE 16
248-255 STAND ALONE
CH. 2 000-255 DIMMER 0 – 100%
CH. 3 000-007 BLACK OUT
008-247 STROBE SLOW TO FAST
248-255 SOUND STROBE
8 CHANNEL MODE
CHANNEL
FUNCTION
CH. 1 000-255 RED LED
CH. 2 000-255 GREEN LED
CH. 3 000-255 BLUE LED
CH. 4 000-255 WHITE LED
CH. 5 DIMMER 0 – 100%
CH. 6 000-007 NO FUNCTION
008-247 STROBE SLOW TO
FAST
248-255 SOUND STROBE
CH. 7 000-007 MANUAL
008-022 COLOR CHASE 1
023-037 COLOR CHASE 2
038-052 COLOR CHASE 3
053-067 COLOR CHASE 4
068-082 COLOR CHASE 5
083-097 COLOR CHASE 6
098-112 COLOR CHASE 7
113-127 COLOR CHASE 8 128-142 COLOR CHASE 9
143-157 COLOR CHASE 10
158-172 COLOR CHASE 11
173-187 COLOR CHASE 12
188-202 COLOR CHASE 13
203-217 COLOR CHASE 14
218-232 COLOR CHASE 15
233-247 COLOR CHASE 16
248-255 STAND ALONE
CH. 8 000-007 HOLD
008-255 SPEED SLOW TO FAST
24/28 CHANNEL MODE
CHANNEL FUNCTION
CH. 1 000-255 DIMMER 0 – 100% RED 1
CH. 2 000-255 DIMMER 0 – 100% GREEN 1
CH. 3 000-255 DIMMER 0 – 100% BLUE 1
CH. 4 000-255 DIMMER 0 – 100% WHITE 1
CH. 5 000-255 DIMMER 0 – 100% RED 2
CH. 6 000-255 DIMMER 0 – 100% GREEN 2
CH. 7 000-255 DIMMER 0 – 100% BLUE 2
CH. 8 000-255 DIMMER 0 – 100% WHITE 2
CH. 9 000-255 DIMMER 0 – 100% RED 3
CH. 10 000-255 DIMMER 0 – 100% GREEN 3
CH. 11 000-255 DIMMER 0 – 100% BLUE 3
CH. 12 000-255 DIMMER 0 – 100% WHITE 3
CH. 13 000-255 DIMMER 0 – 100% RED 4
CH. 14 000-255 DIMMER 0 – 100% GREEN 4
CH. 15 000-255 DIMMER 0 – 100% BLUE 4
CH. 16 000-255 DIMMER 0 – 100% WHITE 4
CH. 17 000-255 DIMMER 0 – 100% RED 5
CH. 18 000-255 DIMMER 0 – 100% GREEN 5
CH. 19 000-255 DIMMER 0 – 100% BLUE 5
CH. 20 000-255 DIMMER 0 – 100% WHITE 5
CH. 21 000-255 DIMMER 0 – 100% RED 6
CH. 22 000-255 DIMMER 0 – 100% GREEN 6
CH. 23 000-255 DIMMER 0 – 100% BLUE 6
CH. 24 000-255 DIMMER 0 – 100% WHITE 6
CH. 25 000-255 DIMMER 0 – 100%
CH. 26 000-007NO FUNCTION
008-247 STROBE SLOW TO FAST
248-255 SOUND STROBE
CH. 27 (SEE 8 CHANNEL MODE, CHANNEL 7)
CH. 28 000-007 HOLD
008-255 SPEED SLOW TO FAST
