OmniSistem WiDMX Transceiver - Manual (Page 13)

This function allows to pair the receiver Wi D Pen to the transmitter Wi
DMX, to avoid interactions with other unit of the same type.
4.6 RECEIVER PAIRING
With MODE key (Fig.17) find the text like in (Fig.18).
Connect Wi D Pen to the D DM MX X 5 51 12 2 ttrra an ns sm miitttte err signal IIN N
(Fig.20/1) without connecting Wi D Pen ac-adapter.
Hold SET key (Fig.19) until a writing appears like in (Fig.20).
After a few seconds a result of the operation is given; if like in (Fig.21) pairing succeeded;
else the message of (Fig.22) appears.
Fig. 17
MODE
SET
Fig. 19
PAIR RECEIVER
Fig. 18
PAIRing
:
wait...
Fig. 20
Fig. 20/1
PAIRing
:
Fig. 21
PAIRing
:
failed!
Fig. 22
