O.S. Engines FS-91 II FI User Manual
Page 26
26
29483300
45985200
27981600
45915000
27881400
45985100
45985110
N.+M3X22
N.+M3X6
1
2
3
4
5
6
8
C.M2.6X8
7
No.
The specifications are subject to alteration for improvement without notice.
INJECTOR AIR VALVE (60T)
EXPLODED VIEW & PARTS LIST
Code No.
Description
Throttle Lever Assembly
Roter Valve
Roter Guide Screw
Injector Air Valve Body
Injector Holder
Injector Set
Gasket
1
2
3
4
5
6
7
