Type of screw
N...Round Head Screw S...Set Screw
The specifications are subject to alteration for improvement without notice.
Description Code No. No.
EXPLODED VIEW & PARTS LIST
Needle Assembly
Needle Holder Assembly
Ratchet Spring
Carburetor Body
Fuel Inlet (Nipple No.1)
Carburetor Rubber Gasket
Roter Guide Screw
Mixture Control Valve Assembly
"O" Ring (2pcs.)
"O" Ring (2pcs.)
Carburetor Rotor
Throttle Lever
Throttle Lever Retaining Screw
Carburetor Retaining Screw (2pcs.) 1
2
2-1
3
4
5
6
7
7-1
7-2
8
9
9-1
10
47181970
27381940
26711305
47181100
22681953
46115000
45581820
47181600
46066319
24881824
47181200
22081408
22081313
45581700
N.+M3x6
S.M3x3
1
2
3
4
5
6
7
8
9
9-1
N.+M3x22
2-1
7-1
7-2
10
33
(46210300)
(71531000)
(72403050)
(79870050) (55500004)
(71521000)
(71531010)
COLLECTOR EXHAUST PIPE
NON-BUBBLE WEIGHT
SUPER FILTER (L) LONG SOCKET WRENCH
WITH PLUG GRIP
O.S. GENUINE PARTS & ACCESSORIES
PROPELLER
LOCKNUT SET FOR 4C SPINNER
The specifications are subject to alteration for improvement without notice.
M5
BLIND NUT (10pcs.) LOCK WASHER (10sets)
M5
NON-BUBBLE WEIGHT
S
3/8"-M5 (L)
(47169000)
