Name
*For the 140RX
*T-6010
*Type F
General references:
*16x14(2 blades)
15x12(4 blades)
15x13.5(3 blades)
15x14(3 blades)
10-25% nitromethane
15-20% oil
*1024ZA
FF8A
PCM10S
PCM10X
X3810
STYLUS
The following components are required during installation: EC-1, y harness, check valve, fuel
filter, manifold (sold separately), T-6010 silencer (sold separately), extension cord (sold
separately), double-sided, sponge-backed cushioning tape.
A soft engine mount is recommended but should be made of firm enough material to prevent
excessive engine movement but still minimize engine vibration. If engine vibration is excessive
the opening angle of the air valve may vary causing unstable engine operation and possible
stalling. In addition, adequate clearance must be provided to ensure there is no contact
between the injector, temperature sensor and rotation sensor with the airframe.
List of 140RX-FI Usage Conditions
Part Manufacturer Remarks
Exhaust manifold
Tuned silencer
Glow plug
Propeller
O.S.
O.S.
O.S.
Commercially
available
high-quality
product
Mid-range engine speed
should be approximately
6,500 rpm.
Maximun speed should be
between 7,300 and 8,000
rpm.
Fuel Commercially
available
high-quality
product
For 2m class F3A Aircraft
Only Z connectors can be
used (check whether polarity
matches).
Spare channel dial (used at
100% by canceling mixing
and expo, etc. when used
alone.
Adjustment may vary slightly
according to the amounts of
nitromethane and oil.
Transmitter FUTABA
FUTABA
JR
JR
JR
SANWA
The contents of the user's manual are based on those products indicated with an asterisk (*).
Installation Procedure
Install the 140RX FI while taking the following matters into consideration.
(1) MAX-140RX FI Engine
(2) Engine Mount
10
