36
(L) (72403050)
(71705000)
(55500002)
(71608001)
No.8
(71605300)
A3
(71605100)
A5
(27708010)
(27708200)
(71530400) 3246
(71521000) (79871055)
M3
LONG SOCKET WRENCH
WITH PLUG GRIP
SUPER FILTER IN-FLIGHT CONTROL
NEEDLE VALVE
LOCK WASHER
(10set)
O.S. GENUINE PARTS & ACCESSORIES
The specifications are subject to alteration for improvement without notice.
GLOWPLUG DRIVE HUB ASSEMBLY
(w / woodruff key)
Drive Hub
Woodruff Key
CRANKSHAFT CLAMP
M2.6x18
CAP SCREW SET
(10pcs.)
37
THREE VIEW DRAWING
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
SPECIFICATIONS
Dimensions(mm)
Please note that this engine is not supplied with Drive Hub. NOTE:
8.17 cc (0.499 cu.in.)
22.0mm (0.866 in.)
21.5mm (0.847 in.)
2,000-20,000 r.p.m.
1.9 ps / 17,000 r.p.m.
406g (14.33 oz.)
UNF1/4-28
52
36
38
31
26.8
18.3
60.7 25
74
37.7
11
37
51.6
44
17.5
54 47
