Three view drawing – O.S. Engines 12XZ Speed Spec II User Manual
Page 20
38
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
THREE VIEW DRAWING
Dimensions (mm)
2.1 cc (0.128 cu.in.)
13.8 mm (0.543 in.)
14.0 mm (0.551 in.)
5,000-44,000 r.p.m.
1.75 ps / 35,000 r.p.m.
220g (7.76 oz.)
25.4
39
70.6
15.1
34.9
29.5
UNF1/4-28
1
11
31.4
4- 3.3
C
Copyright 2010 by O.S.Engines Mfg. Co., Ltd. All rights reserved. Printed in Japan.
60092370 061000
TEL. (06) 6702-0225
FAX. (06) 6704-2722
6-15 3-Chome Imagawa Higashisumiyoshi-ku
Osaka 546-0003, Japan
