Product operation method
5 seconds later, the following main interface is displayed:
Bootscreen
Synchronous self test ( self test dynamically displayed in the line
from left to right)
- - - - --
05
welcome
to choose noyafa
N F - 8 2 0 0
There are three functional options in the main menu interface
(1)
(2)
(3)
Note:
Calibration— Seven calibration coefficient can be stored in it.
User can calibrate network/ Telephone cable.
Data loading---Select the calibration coefficients stored in system.
. RJ45 — wiremapping / length measurement /
cable tracing / crosstalk testing
. RJ11 — wiremapping / length measurement /
cable tracing / crosstalk testing
. Setup— unit / brightness/ auto-power-off time
- - - - identify- - - -
Taking network test as an example: after entering RJ45 function to check
wire mapping.At this time, the following interface is shown indicating test
is in process:
a.Cable line-to-line test:
Scan Cable
C a b l e L e n g t h
Wire Mapping
NOYAFA
Test result 1: Short circuit
Short mapping:
1 2 3 4 5 6 7 8
Cable open or
too Short !
If there is short circuit with the cable and terminal, it will show as below:
(Short circuit with 3 and 6)
At this time, press any key to return to the main menu, and then press
“ENTER” key for re-test.
Please do not perform test again until short circuit problem solved.
Test result 2: if the far end of the cable to be tested is not plugged in
remote adapter (R) or cable is not plugged into the local port (S),
the following interface is shown:
Test result 3:correct connection
the following interface is shown :
“M”stands for Master unit. “R” stands for remote unit “G” stands
for “Grounded”.
06
1 2 3 4 5 6 7 8 G M:
R: 1 2 3 4 5 6 7 8 G
Wire Map: Remote
NOYAFA
RJ45 RJ11 Setup
